Arc Lounge
A Responsible Chair
Premium flat pack furniture
The Arc Lounge is a thoughtfully designed, flat-packable lounge chair made from white oak, featuring interchangeable ultra-suede upholstery and simple knock-down hardware. Inspired by the fluid forms of Gaudí’s
architecture in Barcelona, its curved backrest explores the natural flexibility of wood. Crafted with a mix of CNC milling and hand-finishing, and treated with Danish oil, the Arc is built to age gracefully over time.
Economic Research
Measurements and analysis of existing seating solutions to guide the dimensions and ergonomics of ARC.
Design Inpiration
10th Scale Models
Five sketches chosen to influence 10th scale models.
Full Scale Prototype
One scale model was selected to continue with in full scale prototyping
User Testing Insights
-
Refine connection of backrest support to the arms.
-
Bring seat back forward and relax the angle.
-
Raise seat by 4 inches.
-
Protect legs and feet of the chair from chipping.
-
Upholster seat and backrest.
CAD for CNC
Prototype refinements integrated into CAD model built in Rhino 8 using surfacing tools.
CAD Objectives
-
Design for manufacturing using 3-axis CNC and associated work holding.
-
Thoughtful hardware integration.
-
Create molds for bent ply seat and backrest.
Glue Lamination
Molds were designed in CAD and cut using CNC for creating bent plywood laminations for the seat and backrest.
%202.jpeg)
%202.jpeg)
%202.jpeg)
%202.jpeg)
%202.jpeg)
%202.jpeg)
CNC Production
The legs and rough outline of the arc back support were milled out of locally sourced Oregon White Oak.
%202.jpeg)
%202.jpeg)
%202.jpeg)
%202.jpeg)
%202.jpeg)
%202.jpeg)
Component Assembly
Components were hand shaped and carved to perfection before final assembly.
%202.jpeg)
Upholstery and Final Assembly
Finished in danish oil and ultra suede upholstery, assembled using only six standard furniture bolts.
.jpeg)
.jpeg)
%202.jpeg)
The Arc Lounge Chair
A flat-packable, Oregon White Oak Lounge Chair with ultra suede upholstery and a gravity-defying design.
Sketching
Initial sketching inspired by Gaudi's architecture. Forms were develop and refine concepts before working on 1/10th scale models
All Projects
What if flat pack furniture wasn't associated with low build quality and cheap materials that were meant to be thrown away instead of repaired or refurbished?
Confronting the norm, the Arc Lounge is a flat packable, premium crafted product built to stand the test of time.
Skills
Sketching, Woodworking,
scale prototyping, Rhino 8,
CNC, Keyshot.
Professor
John Arndt
Timeline
10 Weeks
